Long Range UHF RFID Reader RJ45 WG RS232 Trigger
Working frequency: National standard (920~9251Hz)
American standard (902~ 928MHz).
European standard (865~ 868MHz)
Other multinational frequency standards (customized)
Description
Long Range UHF RFID Reader RJ45 WG RS232 Trigger
Model No.: UHF-106
Product Features
>Low power, stable and reliable reading and writing distance;
>Fast data reading rate;
>Tag wake-up recognition;
>Multi-region and multi-tag reading;
>Multi-protocol compatible;
>Waterproof appearance design;
| System parameters | AFMT+UHF module |
| Working frequency | National standard (920~9251Hz) |
| American standard (902~ 928MHz). | |
| European standard (865~ 868MHz) | |
| Other multinational frequency standards (customized) | |
| Recognition distance | >6 meters |
| Group read performance | >50 tags |
| Tag protocol | Supports IS01 8000-6C (EPC GEN2) protocol electronic tags |
| Frequency hopping | Wide spectrum frequency hopping (FHSS) or fixed frequency, which can be set by software; |
| Way of working | Automatic mode, trigger mode, interactive mode, etc. |
| RF power | 0-30dBm (power software adjustable) |
| Antenna parameters | 8dBi circularly polarized antenna (built-in) |
| Support interface | Standard RS232, RS485, Wieg and26, WVi egand34, optional RJ45, WIFI, GPRS, etc |
| Operating Voltage | +12V |
| Identify tips | Beeps or LED flashes |
| Power consumption | <1W |
| Operating temperature | -20 C ~ +70 C (out of range needs to be customized) |
| Working humidity | 20% ~ 95% (no condensation) |
| Storage temperature | -40 C, +125 C |
| Size | 180x180x47mm |
| Net weight | 900G |
| gross weight | 1500G |
